SO-CR-R-F-20-55-CCT-103-70-BW

Technical Data

Model Reference

SO-CR-R-F-15-55-CCT-83-65-BW

Power (Wattage)

15W

Lumen Output

1125lm

Luminous Effficiency

75Lm/W

CRI

CRI>90

Colour Temperature(CCT)

2700 / 3000K / 4000K / 6000K

Finish

White

IP rating

IP20

Dimension

83mm x 65mm

Ambient Working Temperature

-25° to +50°

Chip Type

COB

Optics

55°

Cut out

Ø75

Control Option

on-off / Triac / 0-10V / Dali
